When the vehicle enters the weighing lane, the vehicle separator detects the arrival of the vehicle, and generates a signal to notify the weighing controller to enter the weighing working state; when the quartz sensor weighs each axis of the vehicle in turn, the load of each axis is measured in real time, and the load of each axis is measured in real time. Send it to the weighing controller for recording; when the vehicle passes completely, the vehicle separator generates a signal to notify the weighing controller to enter the data processing state; in the data processing state, the weighing controller accumulates the recorded axle weight and calculates the vehicle It calculates whether the vehicle exceeds the limit and the specific number of overruns according to the detected vehicle type classification, and outputs data such as the vehicle type classification, the total vehicle load, and the vehicle limit.
1. The axle, axle group and vehicle weight of the vehicle can be detected;
2. The vehicle speed can be detected;
3. Can basically distinguish the type of vehicle (by the number of axles, axle type);
4. Able to record the passing time of vehicles;
5. The over-limit weight limit can be set according to the requirements of the over-limit vehicle identification standard, and can be easily adjusted;
6. Automatically determine whether the vehicle exceeds the limit;
7. Able to handle the weighing process by itself;
8. Complete vehicle weighing information can be formed, including vehicle weight, axle group weight, vehicle weight, axle type, vehicle model, vehicle speed, vehicle overrun sign, time, etc.
